CitySTREAM 412UE

12-metre urban electric bus

DAC CitySTREAM 412UE is a 12-metre urban electric bus with a low floor, designed for intensive public transport. The model combines the ruggedness and reliability associated with the DAC tradition with modern electric technology and components from established suppliers.

12 m

Length

97 passengers

Capacity

451 km

Range

370 kW

Power

Request information

1 / 7

CitySTREAM 412UE is DAC's model for high-capacity urban routes, intended for operators who need long range, passenger comfort, and optimized operating costs.

Main application

Urban and metropolitan public transport.

Target applications

Main urban lines

Metropolitan transport

High-traffic municipal networks

Urban routes with heavy passenger flow

Operational advantage

CitySTREAM 412UE is designed for intensive daily operation on main urban routes. Its long range covers most routes on a single charge, and premium components deliver long-term reliability.

Economic advantage

Electric buses are economically advantageous through lower operating costs, higher energy efficiency, and reduced maintenance time. The range covers most urban routes with overnight charging.

Technical description

DAC CitySTREAM 412UE is a 12-metre electric bus with three doors and a low floor. Dimensions 12,200 × 2,550 × 3,300 mm, wheelbase 5,840 mm, gross vehicle weight 19,500 kg, curb weight 13,750 kg. Available with battery capacities of 256.1, 282.6, 384.2 or 423.9 kWh, and equipped with a DANA TM4 motor of 370 kW and 3,700 Nm. Top speed is 80 km/h, and maximum passenger capacity reaches 97. eSORT range is 397–451 km on the 423 kWh battery, with a charge time of 2.5–3 hours from 20% to 100%.

Key specifications

12 m bus, low floor, 3 doors	✓
Gross vehicle weight	19,500 kg
Curb weight	13,750 kg
Battery variants	256.1 / 282.6 / 384.2 / 423.9 kWh
eSORT range	397–451 km
DANA TM4 motor	370 kW / 3,700 Nm
Top speed	80 km/h
Max capacity	97 passengers
32 fixed seats, 2 foldable	✓
Pneumatic suspension	✓
Regenerative braking	✓
KNORR, ZF, BOSCH systems	✓
Climate control with thermal management	✓
7" reverse display, 8 cameras	✓
AutoHold and Hill Assist	✓
Disability ramp and kneeling function	✓
Full LED lighting	✓
Charge time	2.5–3 hours (20%–100%)

Benefits for operators

Long range for daily urban routes
Lower maintenance time
Lower operating costs
Configuration suited for intensive duty
Components from established suppliers

Benefits for cities

Lower local pollution
Lower noise
High passenger capacity
A modern image for public transport

Passenger comfort

Low floor
Easy access for reduced-mobility passengers
Spacious cabin
Climate control
LED information display
Space for strollers and wheelchairs

Economic efficiency

Electric buses are economically advantageous through lower operating costs, higher energy efficiency, and reduced maintenance time. The range covers most urban routes with overnight charging.
